Cross-linkable polyethylene (PE) foam
Cross-linkable polyethylene foam is a type of closed-cell foam excellent in heat insulation, shock-absorbing property, sound proof and chemical resistance. It is particularly light with high performance and widely used in various industries such as construction, civil engineering, and housewares.
Basic property table
Category Unit Reference value Remark
Operating Temperature Range 70 120 KS M 3862
Tensile Strength N/㎠ 14.7 above 24.5 above
Thickness Shrinkage % (70±5℃) 7 below (120±5℃) 7 below
Absorbency g/100cm² 0.01 below
Manufacturing Standards
Category Unit Reference value Remark
Density g/cm² 0..188 ~ 0.025 5 ~ 40 times
Production thickness mm 3 ~ 15 allowable error ±10%
Product width mm 1,000 ~ 2,300
Applications

01. Construction

  • Refrigerant piping
  • Piping insulation
  • Roof insulation
  • Duct insulation
  • Building insulation
  • Sound insulation
  • Elastic sound absorbing Material
  • Floor insulation

02. Automotive Sector

  • Door panel
  • Side panel
  • Gasket
  • Air duct

03. Housewares

  • Insulated wallpaper
  • Floor mat
  • Fruit package
  • Life jacket
